A global network of radio telescopes exposes the aftermath of a violent merger of neutron stars

Published on 21 February 2019
Network of telescopes


Astronomers have combined radio telescopes from five continents to prove the existence of a narrow stream of material (jet) emerging from the only gravitational wave event involving two neutron stars observed so far.

In August 2017, two neutron stars were observed colliding, producing gravitational waves that were detected by the American LIGO and European Virgo detectors. Neutron stars are ultra-dense stars, roughly the same mass as the Sun, but similar in size to a city like Amsterdam. This event is the first and only one of this type that has been observed so far, and it happened in a galaxy 130 million lightyears away from Earth. Astronomers observed the event and the subsequent evolution across the entire electromagnetic spectrum, from gamma-rays, X-rays to visible light and radio waves. Two hundred days after the merger, observations combining radio telescopes in Europe, Africa, Asia, Oceania, and North America proved the existence of a jet emerging from this violent collision. These findings have been published in the scientific journal Science by an international team of astronomers, led by Giancarlo Ghirlanda from the National Institute for Astrophysics (INAF, Italy).

This neutron star merger represented the first case where it was possible to associate a detection of gravitational waves to an object emitting light. The event has confirmed scientific theories that have been under discussion for tens of years, and the association of neutron star mergers with one of the most powerful explosions in the Universe: gamma-ray bursts. After the merger, a huge amount of material was expelled into space, forming a shell around the object. Astronomers have been tracing its evolution at different wavelengths. However, there were still some remaining questions concerning this event that could not be clarified by any previous observations. "We expected part of the material to be ejected through a collimated jet, but it was unclear whether this material could successfully pierce through the surrounding shell." explains Ghirlanda. “There were two competing scenarios: In one case, the jet can not break through the shell, instead generating an expanding bubble around the object. In the other, the jet is successful in penetrating the shell and then propagates further into space”, expands Tiziana Venturi (INAF). Only the acquisition of very sensitive radio images with very high resolution would discard one scenario or the other. This required the use of a technique known as Very Long Baseline Interferometry (VLBI) that allows astronomers to combine radio telescopes all around the Earth.
The authors of this publication conducted global observations in the direction of the merger on 12 March 2018 using 33 radio telescopes from the European VLBI Network (that connects telescopes from Spain, the United Kingdom, The Netherlands, Germany, Italy, Sweden, Poland, Latvia, SouthAfrica, Russia, and China), e-MERLIN in the UK, the Australian Long Baseline Array in Australia and New Zealand, and the Very Long Baseline Array in the USA. The data from all telescopes were sent to the Joint Institute for VLBI ERIC (JIVE, in the Netherlands), where the most advanced processing techniques were used to produce an image with a resolution comparable to resolving a person on the surface of the Moon. In the same analogy, the expanding bubble would appear with an apparent size equivalent to a truck on the Moon, whereas a successful jet would be detected as a much more compact object. "Comparing the theoretical images with the real ones, we find that only a jet could appear sufficiently compact to be compatible with the observed size.", explains Om Sharan Salafia (INAF). The team determined that this jet contained as much energy as produced by all the stars in our Galaxy during one year. “And all that energy was contained in a size smaller than one light year.” says Zsolt Paragi (JIVE).
In the coming years, many more of these neutron star binary mergers will be discovered. “The obtained results also suggest that more than 10% of all these mergers should exhibit a successful jet.”, explains Benito Marcote (JIVE). "These types of observations will allow us to unveil the processes that take place during and after some of the most powerful events in the Universe.", concludes Sándor Frey (Konkoly Observatory, Hungary).
This study appeared on the 22 February 2019 volume of Science (http://science.sciencemag.org/content/early/2019/02/20/science.aau8815) and was led by Giancarlo Ghirlanda from the National Institute for Astrophysics (INAF, Italy).


Katharina Immer - Interim Science Communication Officer
The Joint Institute for VLBI ERIC (JIVE)
Email: immer@jive.eu
Phone: +31 521 596 507
Giancarlo Ghirlanda - Corresponding author
Instituto Nazionale di Astrofisica (INAF)
Email: giancarlo.ghirlanda@brera.inaf.it
Phone: +39 0 395 971 095
Zsolt Paragi - co-author
The Joint Institute for VLBI ERIC (JIVE)
Email: zparagi@jive.eu
Phone: +31 521 596 536

Additional Information

VLBI is an astronomical method by which multiple radio telescopes distributed across great distances observe the same region of sky simultaneously. Data from each telescope is sent to a central "correlator" to produce images with higher resolution than the most powerful optical telescopes.
The European VLBI Network (EVN; www.evlbi.org) is an interferometric array of radio telescopes spread throughout Europe, Asia, South Africa and the Americas that conducts unique, high-resolution, radio astronomical observations of cosmic radio sources. Established in 1980, the EVN has grown into
the most sensitive VLBI array in the world, including over 20 individual telescopes, among them some of the world's largest and most sensitive radio telescopes. The EVN is administered by the European Consortium for VLBI, which includes a total of 15 institutes, including the Joint Institute for VLBI ERIC (JIVE).
Thirty three radio telescopes participated in this observation: Yebes (Spain), Jodrell Bank (UK), e-MERLIN (UK), Westerbork (The Netherlands), Effelsberg (Germany), Medicina (Italy), Onsala (Sweden), Noto (Italy), Toruń (Poland), Irbene (Latvia), Hartebeesthoek (South Africa), Zelenchukskaya (Russia), Urumqi (China), Badary (Russia), Kunming (China), Tianma (China), Ceduna (Australia), Hobart (Australia), Parkes (Australia), Mopra (Australia), Australia Telescope Compact Array (Australia), Warkworth (New Zealand), Mauna Kea (USA), Brewster (USA), Owens Valley (USA), Kitt Peak (USA), Pie Town (USA), Karl G. Jansky Very Large Array (USA), Los Alamos (USA), Fort Davis (USA), North Liberty (USA), Green Bank (USA), Hancock (USA), and St. Croix (USA).
The Joint Institute for VLBI ERIC (JIVE; www.jive.eu) has as its primary mission to operate and develop the EVN data processor, a powerful supercomputer that combines the signals from radio telescopes located across the planet. Founded in 1993, JIVE is since 2015 a European Research Infrastructure Consortium (ERIC) with six member countries: France, Latvia, the Netherlands, United Kingdom, Spain and Sweden; additional support is received from partner institutes in China, Germany, Italy and South Africa. JIVE is hosted at the offices of the Netherlands Institute for Radio Astronomy (ASTRON) in the Netherlands.

Image description and credits

Upper panel: Representation of all radio telescopes that participated in this observation. Credit: Paul
Boven (JIVE).
Lower panel, left: Artist’s impression of the merger of two neutron stars with all the material expelled into space and the observed jet after breaking through this shell. Credit: Beabudai Design.
Lower panel, middle:  Image of the source obtained from the combination of 33 radio telescopes from five continents. The source can be seen in the center of the image as a red spot (false color image made entirely for illustration). Credit: Giancarlo Ghirlanda/Science.
Lower panel, right: Artist’s impression of the jet of material launched after the merger of the two neutron stars. Credit: Katharina Immer (JIVE).
